Conbraco D-1606-00 Gasket

The Resideo R8222N1011 is a DPDT switching relay designed for demanding HVACR and industrial control applications. This 24V general purpose relay provides heavy-duty pilot duty switching for refrigeration systems, air conditioning equipment, and appliances. Built with laminated magnet construction for superior efficiency and an untaped coil for cooler operation, it ensures high reliability in high-cycle environments. The low voltage switching capability makes it a standard choice for interfacing between controllers and power loads across multi-circuit systems. Measuring 2-5/32 in. W x 2-3/8 in. D x 1-7/8 in. H, the compact housing fits easily into standard electrical boxes or control panels. Molded terminal numbers and a permanent circuit diagram on the top of the relay allow for rapid wiring and simplified troubleshooting in the field. This unit features double quick-connect coil terminals and is fully plug-compatible with industry-standard components like the Mars 90340 and Steveco 90-340, streamlining the replacement process for service technicians.

• High-Efficiency Performance: Features laminated magnet construction and an open, untaped coil design to reduce heat buildup and electrical losses.
• Universal Compatibility: Direct cross-reference for Steveco 90-340 and Mars 90340, allowing for seamless integration into existing 24V AC control circuits.
• Versatile Electrical Ratings: Supports up to 12A AFL at 120 VAC and 20.8A resistive loads at 277 VAC for robust switching relay applications.
• Rugged Design: Built to withstand operating temperatures from -20°F to 155°F, making it suitable for both refrigeration and heating cabinetry.

Is the coil compatible with DC power?
No, the R8222N1011 is specifically engineered for 24V AC, 50/60 Hz operation. Using a DC power source will prevent the magnet from seating properly and may cause coil failure.

Can this relay handle inductive motor loads?
Yes, it is rated for full load amps (AFL) of 12A at 120V and 6A at 240V. For locked rotor conditions, it can handle up to 60A at 120V, providing sufficient overhead for compressor-run or fan motor starts.

How do I identify the terminal connections?
The technical specifications are printed directly on the relay. Each terminal is molded with identification numbers and a wiring diagram is displayed on the top face for quick field verification of the DPDT contact state.
