Nordyne 903660 Flue Pipe Kit
The Copeland CR32K6E-PFV-875 is a high-performance, 2.5-ton hermetic reciprocating compressor engineered for demanding air conditioning and heat pump applications. As a 6th generation Copeland CR series model, it delivers a rated capacity of 32,000 BTU/hr at standard 45°F evaporator conditions. Designed for versatility, this unit is R-407C and R-22 compatible and comes pre-charged with POE oil, making it an ideal choice for both new installations and R-22 dry-charge retrofits where mineral oil is no longer suitable.
Operating on a 208/230V, single-phase, 60Hz power supply, the CR32K6E-PFV-875 features a 3/4" suction and 1/2" discharge ODF sweat connection. This specific -875 bill-of-material is a comprehensive service kit that includes a 42-inch molded plug wiring harness, mounting hardware, and necessary internal line break overloads for robust motor protection. For contractors performing a compressor cross-reference, this unit directly replaces several legacy models including the CR32K6-PFV and CR32K6-PFV-230, ensuring a streamlined drop-in replacement process in the field.
- Multi-Refrigerant Capability: Optimized for use with R407C refrigerant and legacy R22 systems.
- Complete Service Kit: Includes a molded plug harness and mounting kit to reduce installation time.
- Reliable Lubrication: Charged with 45 oz of Polyolester (POE) oil for superior moisture management and lubrication.
- Efficient Performance: Rated at 10.8 EER, minimizing operational costs for residential and light commercial systems.
- Robust Protection: Features internal overloads to prevent motor failure during high-amperage events.
Common Questions
What capacitor is required for the CR32K6E-PFV-875?
This compressor typically requires a 35 µF / 440V run capacitor. Always verify the motor nameplate and fan requirements if using a dual-run capacitor.
Can I use this compressor to replace a ZR scroll compressor?
While both are used in A/C applications, reciprocating and scroll compressors have different footprints and piping requirements. Consult the Copeland cross-reference guide to ensure mounting and piping compatibility.
Is this unit backward compatible with R-22 mineral oil systems?
Yes, the CR32K6E-PFV-875 is backward compatible; however, ensure the system is properly cleaned and the POE oil is not contaminated by excessive residual mineral oil during the swap.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
