Watts R10-0313A Regulator

The Watts R10-0313A Regulator is a precision-engineered pneumatic pressure regulator designed for high-performance air preparation in industrial environments. Featuring 3/8" NPT ports and a secondary 2-125 PSI pressure range, this unit ensures stable downstream pressure even during significant fluctuations in the primary supply. As the direct replacement for R10-03C, it maintains the same footprint while offering improved response times through a balanced poppet design and rolling diaphragm technology. This relieving type regulator is critical for protecting sensitive pneumatic tools and machinery from over-pressurization. The non-rising adjustment knob provides smooth control across the 0-125 PSIG spectrum, making it a reliable choice for compressed air systems. Built with a robust zinc body and Buna-N seals, this Parker Watts R10 series component is optimized for maximum flow capacity and long-term durability in demanding contractor applications.

• Optimized Pressure Control: Provides a precise 2-125 PSI range to prevent equipment damage and ensure consistent tool performance.
• High-Flow Design: Engineered with a balanced poppet to maintain maximum SCFM flow with minimal pressure drop.
• Direct Cross-Reference: Serves as the official replacement for Watts R10-03C, allowing for seamless drop-in installation without repiping.
• Industrial Durability: Features a high-strength body and rolling diaphragm for extended service life in high-cycle pneumatic applications.
• Tamper Resistance: Includes a removable adjustment knob, perfect for maintaining set points in critical process regulation environments.

• What is the maximum inlet pressure for the Watts R10-0313A? This regulator is rated for a maximum primary pressure of up to 300 PSIG, though it is standardly used in 100-125 PSIG systems.
• Does this model include a pressure gauge? No, the R10-0313A does not include a gauge, but it features two 1/4" NPT gauge ports for easy installation of a standard dial or digital pressure gauge.
• Can this regulator be used for water or liquid service? No, this is a pneumatic air regulator specifically designed for compressed air. Using it for liquid service may lead to diaphragm failure or improper regulation.

Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
