York S1-024-36022-000 Relay

The York S1-024-36022-000 Relay is a heavy-duty, field-replaceable 24V HVAC relay designed for demanding residential and light commercial applications. This OEM York replacement part (cross-reference 209A84) is engineered to manage critical switching operations for blower motors, compressors, and auxiliary heat circuits. Its 24V AC coil configuration integrates seamlessly with standard low-voltage control systems, ensuring precise signal response and circuit isolation. When troubleshooting erratic fan operation or ignition sequences, this relay provides the reliability needed to restore factory-spec performance. With a focus on durability, the S1-024-36022-000 features robust contact points capable of handling high-inrush currents common in inductive loads. For technicians, the standard mounting footprint and clearly marked terminals simplify the installation process, reducing time on the job site while maintaining the integrity of the York air handler or furnace control logic. This is an essential component for maintaining HVAC system reliability and efficient electrical distribution.

• OEM Compatibility: Specifically designed as a direct York S1-024-36022-000 replacement to ensure perfect fit and electrical matching with original equipment.
• Precise Switching: Operates on a standard 24V control signal to provide reliable activation and deactivation of high-voltage components.
• Versatile Application: Suitable for controlling fan motors, heat pumps, and AC condensers that utilize potential or switching relays.
• Durable Construction: Built to withstand the thermal cycles and electrical stress inherent in HVACR environments.

• What are the symptoms of a failing York 24V relay? Common signs include a humming noise from the control board, a blower motor that stays on constantly, or a unit that fails to kick on despite a signal from the thermostat.
• Can this relay be used in non-York equipment? While engineered for York, it fits many systems requiring a 24V AC coil relay with similar terminal configurations; always verify amperage ratings and pinouts before installation.
• How do I test the S1-024-36022-000 for continuity? Using a multimeter, check for resistance across the coil terminals (typically 1 and 3) to ensure the coil isn't open, then verify the normally open/closed contacts under 24V load.

Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
