Fireye UV7R4 Scanner

1/2"NPT UV 90 Deg UV SCANNER

Fireye UV7R4 Flame Scanner – 1/2" NPT 90° Right Angle UV Flame Detector

The Fireye UV7R4 Scanner is a high-sensitivity, right-angle ultraviolet (UV) flame scanner designed for accurate and reliable flame detection in gas and oil-fired systems. Featuring a 90° right-angle configuration and 1/2" NPT connection, the UV7R4 is ideal for applications with space constraints or specific mounting requirements.

Key Features:

• High-Sensitivity UV Detection: Accurately monitors flames that cycle on and off frequently in gas or oil systems.

• Flame Safeguard Protection: Built-in flame safeguard system checks for short-circuited or runaway scanners during each cycle to maintain system safety.

• Durable and Safe: UL listed and FM approved for industrial-grade performance and safety assurance.

• Flexible Installation: 72-inch (1830mm) unshielded lead wires and reverse connection protection for secure and adaptable setup.

• Robust Design: Constructed for long-term operation in demanding industrial environments.

How It Works: The UV7R4 uses a quartz UV tube filled with gas that ionizes in the presence of UV radiation emitted by a flame. This ionization allows current to flow between electrodes, generating a signal that is sent to the amplifier. The processed signal maintains or energizes the flame relay, ensuring the burner operates safely and efficiently.

Technical Specifications:

• Model: UV7R4

• Connection Size: 1/2" NPT

• Detection Angle: 90° Right Angle

• Cable: 72-inch unshielded lead wires

• Certifications: UL Listed, FM Approved

• Protection Features: Reverse connection protection and flame safeguard monitoring

Applications:

• Industrial Boilers

• Commercial Gas and Oil Burners

• Process Heating Equipment

• Power Generation Systems

Benefits:

• Reliable flame monitoring for continuous and cyclic operation.

• Enhanced safety with automatic scanner fault detection.

• Easy to install in tight or uniquely configured spaces.

• Built to meet rigorous industry standards for performance and durability.

Trust Fireye UV7R4 for critical flame detection and safeguard your system with industry-leading reliability!
