Johnson Controls VG7441LT Valve

The Johnson Controls VG7441LT is a heavy-duty 2-way normally closed globe valve engineered specifically for precise hydronic control and saturated steam applications in commercial HVACR systems. Utilizing a 3/4 inch NPT connection, this cast bronze body valve features brass trim and a stainless steel stem, ensuring high durability and resistance to scaling in tough environments. With a 7.3 Cv rating and equal percentage flow characteristics, it provides the linear-to-load response required for stable temperature regulation in chilled water or hot water coils. Designed for a push down to open action, the VG7441LT identifies as a reliable solution for terminal unit control and reheat coil management. The ANSI Class 250 pressure rating and standard threaded stem allow for seamless integration with a wide variety of VG7000 series pneumatic or electric actuators, offering contractors flexibility for both new installs and field retrofits.

• High-Precision Control: The equal percentage flow characteristic ensures accurate modulation and stable discharge temperatures.
• Robust Construction: A cast bronze body and brass trim provide long-term reliability in saturated steam up to 38 psig.
• Superior Sealing: Features ANSI Class IV leakage protection with a 0.01% maximum flow rating to prevent energy waste.
• Broad Compatibility: The 3/4" NPT threaded ports and standard stem design support a wide range of Johnson Controls actuators.
• Thermal Versatility: Rated for fluid temperatures ranging from 35°F to 284°F, making it suitable for glycol, water, and steam.

• What actuators are compatible with the VG7441LT? This valve body is designed for use with VA-715x, VA-4233, and M9000 series actuators, as well as V-3000 pneumatic assemblies.
• Can this valve be used for steam service? Yes, the brass trim and EPR packing are rated for saturated steam up to 38 psig (262 kPa).
• Is the flow direction reversible? No, for normally closed operation, ensure the flow follows the direction indicated on the valve body to maintain proper shutoff and CV flow performance.

Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
