ABB AF12-30-10-13 Contactor

ABB AF12-30-10-13 Contactor

ABB

The ABB AF12-30-10-13 Electrical Contactor is a three-pole contactor designed for switching and controlling electrical loads in compatible HVAC, industrial automation, and motor control applications. Part of ABB's AF Series, this 12 amp three-pole contactor features a wide-range electronic coil rated for 100–250V AC/DC control voltage, allowing operation with compatible AC or DC control circuits.

The ABB AF12-30-10-13 contactor includes three normally open main power contacts and one normally open auxiliary contact for control, interlocking, or status indication. Screw terminals provide conventional wiring connections for compatible conductors.

This 100–250V AC/DC coil contactor features a compact construction suitable for electrical control panels and motor starter assemblies.

When replacing an existing ABB AF Series contactor, technicians should verify the utilization category, operating current, motor rating, control voltage, auxiliary contact configuration, and mounting requirements.

Installation should follow ABB technical documentation and applicable electrical codes.

Key Benefits

  • Manufacturer: ABB.

  • Part Number: AF12-30-10-13.

  • Product Series: ABB AF Series.

  • Product Type: Three-pole electrical contactor.

  • Rated Operational Current: 12A AC-3 at 400V.

  • Control Voltage: 100–250V AC/DC electronic coil.

  • Main Contacts: Three normally open power contacts (3 NO).

  • Auxiliary Contact: One normally open contact (1 NO).

  • Terminal Type: Screw terminals.

  • Motor Control Application: Designed for compatible three-phase motor switching and control circuits.

  • Electronic Coil Design: Supports a broad control voltage range using AC or DC power.

  • Compact Construction: Suitable for compatible electrical control panels and motor starter assemblies.

  • Industrial Applications: Designed for motor control, automation, and electrical switching systems.

  • Replacement Compatibility: Requires verification of electrical ratings, contact configuration, and mounting specifications.

Common Questions

What are the specifications of the ABB AF12-30-10-13 contactor?

The ABB AF12-30-10-13 is a three-pole electrical contactor with a 12A AC-3 rating at 400V, a 100–250V AC/DC electronic control coil, three normally open main contacts, one normally open auxiliary contact, and screw terminals.

Can the ABB AF12-30-10-13 contactor operate with both AC and DC control voltage?

Yes. The ABB AF12-30-10-13 features an electronic coil designed for compatible AC and DC control supplies within the specified 100–250V range. Technicians should verify the applicable frequency and control circuit requirements using ABB technical documentation.

Can the ABB AF12-30-10-13 replace another 12A three-pole contactor?

Yes, provided the replacement meets the equipment's required utilization category, load current, motor rating, control voltage, auxiliary contact configuration, terminal arrangement, and mounting specifications. Matching amperage alone does not establish compatibility.

Disclaimer

While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.

AF12-30-10-13 is the cross for A12-30-10-84
